Collection Basics

In this module, you'll become familiar with the simulated REST server, and then set up a simple REST collector in Cribl Stream.

Testing with curl​

note

To verify that the REST server is running, open your Sandbox terminal and run the following command:

curl http://rest-server

You will receive a response:

It's a goat parade! 🐐🐐🐐🐐🐐🐐🐐🐐🐐🐐🐐🐐🐐🐐🐐🐐🐐🐐🐐🐐

Congratulations! You've successfully obtained sample data from the server.

Configure REST Collector in Cribl Stream​

Now we'll configure the same curl command as a REST Collector in Cribl Stream.

caution

We've identified an issue with the current Cribl software release that breaks the instructions in this lab. We'll fix it soon.

For now, you'll need to substitute the following domain name for all examples in the course:

`http://rest-server.${C.env.SANDBOX_NAMESPACE}.svc.cluster.local`

For example, if the instructions tell you to use:

`http://rest-server/goats/are/awesome`

You would use this URL instead:

`http://rest-server.${C.env.SANDBOX_NAMESPACE}.svc.cluster.local/goats/are/awesome`
important

Navigate to the REST Collector Source page. From the top nav of your Cribl Stream Sandbox, with Manage active, select Data > Sources, then select Collectors > REST from the Data Sources page's tiles. Click Add Collector to open the REST > Add Collector modal, which provides the following options and fields.

Note: If you do not see any Collector tiles, make sure you disable any ad blockers on the Cribl Sandbox's browser tab.

  1. In the Collector ID field, enter goat_parade.

  2. In the Collect URL field, enter 'http://rest-server'

    Note: the quotes are important! This is a JavaScript expression–enabled field, and you must either wrap static strings inside quotes (single or double), or use the backtick (```), for template literal (string) evaluation.

  3. At the bottom left, click ► Save & Run. In the Run configuration modal, click Run again.

We'll discuss filtering data later in this course.

In the Preview modal, the resulting goat parade output should match what you obtained using the curl command.

Goat Parade

Conclusion​

You've set up a simple Collector to pull data and generate events from REST API data!

In the next module, you'll understand how Discovery works with Collection...
